Product Features
13.5-inch large drive unit, double elastic wave anddouble magnet long stroke;
Fully sealed ultra-low speaker, Dynamic, natural,powerfuland surrounded with ultra-bass vibrationActive integration with built-in amplifier.All materials meet ROHS requirement.

Technical parameters

Parameter

Specification

Drive Units:

13.5" Driver;

Frequency Response:

20Hz~150Hz;

AmplifierPowerOutput:

3000 wattsRMS short-term;

Sensitivity:

86±3dB/W/m( 100Hz );

CrossoverRange:

80~120Hz;

Inputs:

XLRand RCALine(2VP-P);

Input Impedance:

4Ω；

Signal-to-noise ratio(S/N):

>86dB(100Hz A WEIGHTED);

Avg. MaxOutput @1m:

 121dB;

Features :

0.5W low standby power consumption;

Thermal shutdown; Short circuit and overload

protection;Permanent high frequency protection;

Proprietary DSP module;

Voltage：

AC 220V~240V 50Hz;

Dimensions：

430(L)X430(H)X479(D)mm;

Net weight :

 42Kg;

Gross weight：

 45Kg;

Download

X135 User Manual
